TITAN Vulcan X100 - Intel Core Ultra 7 Series Slim CAD Laptop Computer up to 16 Cores

Home > TITAN HPC Workstations > Mobile HPC Workstations >

TITAN Vulcan X100 - Intel Core Ultra 7 Series Slim CAD Laptop Computer

Alternative Views:

Starting Price: $1,815.00

Availability: Usually Ships in 2 to 3 Weeks
Product Code: VULCAN-X100

Lead Time:

CORE COMPONENTS

CPU / Processor:

Memory:

Monitor:

Battery:

Operating Systems:

VIDEO & AUDIO

Video Card:

M.2 NVMe STORAGE

M.2 NVMe Drives Set 1:

M.2 NVMe Drives Set 2:

COMMUNICATIONS

Bluetooth:

NetWork:

Wireless Lan:

ACCESSORIES

Power Adapter:

WARRANTY

Assembly:

TAA Compliance:

Warranty:

Qty:

Technical Specs

TITAN X100 Vulcan
Intel Core Ultra 7 Series Slim CAD Laptop Computer up to 16 Cores

You have a choice between an Intel Core Ultra 5-225H or Ultra 7-255H, with 14 and 16 cores respectively. Both of these processors offer an excellent mix of performance and power efficiency. This helps make the most of the 73WH battery pack, keeping you on-task and not on the hunt for an outlet.

As standard, the X100 comes with 32GB of RAM, but up to 96GB is possible, bearing in mind that this memory is shared with the Intel Iris Xe integrated GPU. This latest generation of Intel iGPU is power-efficient while offering adequate 3D processing power for CAD.

A single 1TB high-speed NVMe drive is standard in the X100, but you can have up to three drives installed in total.

Bluetooth 5.1 is standard, allowing for modern, low-latency and low-energy devices to operate smoothly. The X100 is Wi-Fi 7 capable, for high-speed wireless communication, and the integrated Ethernet port is rated up to 2.5Gbps.

The aforementioned Thunderbolt 4 also offers Power Delivery (PD) input. Inside are Gen4 x4 PCIe SSD slots. So high-speed peripherals are never an issue.

Of course, if your data is on the network, you’ll still have to wait thanks to slow Wi-Fi, right? Wrong! With the latest Wi-Fi 7 technology, you don’t need to plug in a wired connection to get ultra-fast network data transfers. Assuming, of course, that your infrastructure supports Wi-Fi 7, that is. If not, the X100 offers 2.5Gbps Ethernet.

With the X100 you have a choice of form factor, either a 14” or 16” thin-bezel 1200p monitor, with an anti-glare coating. The cost difference between the two screen options is minimal, so your choice should be based on your ergonomic needs.

Like all Titan Workstations, the X100 is hand-assembled to your specifications and undergoes a 72-hour burn-in test before it ships to you. All Titan Computers mobile workstations come with a one-year standard parts & labor warranty, and one year of business-hour support.

Rear Panel Ports:
1 Built-in 1.0M HD Video Camera
1 HDMI output Port (with HDCP)
1 1 Thunderbolt 4 combo port with Power Delivery DC in (Type C)
1 USB 3.2 Gen 2 Port with Power Delivery DC in (Type C)
1 USB 3.2 Gen 2 Port (Type-A) (1x Powered USB port, AC/DC)
1 USB 3.2 Gen 1 Port (Type-A)
1 2-in-1 Audio Jack (Headphone / Microphone)
1 RJ-45 LAN (10/100/1000Mbps)
Micro SD Push-Push Card reader

Security (Kensington Type) Lock Slot
Intel PTT (Platform Trust Technology)

Storage Related:
3 x M.2 slots (Key M)

Dimensions for 14":
- Dimensions: 14.10" (w) x 10.18" (d) x 0.71" (h)
- Weight: 3.22 Lbs with Battery Pack

Dimensions for 16":
- Dimensions: 15.83" (w) x 12.60" (d) x 1.10" (h)
- Weight: 3.86 Lbs with Battery Pack

Availability:
Usually Ships in 2 to 3 weeks

Product Code:
Vulcan-X100
