TITAN W69 - Intel Xeon 6900 Series LGA 7529 High Performance for AI and Machine Learning Workstation PC

Home > TITAN HPC Workstations > Workstation PCs by CPU > Intel 6th Gen Xeon 6 Workstations - up to 288 Cores >

Alternative Views:

Starting Price: $14,039.00

Availability: Usually Ships in 2 to 3 Weeks
Product Code: W69

Lead Time:

CORE COMPONENTS

Case:

Case Fans:

CPU / Processor:

CPU Cooling:

Motherboard:

Memory:

Power:

Operating Systems:

VIDEO & AUDIO

Video Graphics Cards (GPUs):

Sound Card:

LED Monitors:

M.2 NVMe STORAGE

M.2 NVMe Drives Set 1:

M.2 NVMe Drives Set 2:

PCIe M.2 NVMe Controller w/ drives:

SSD & SATA STORAGE

Hard Drives Set 1:

Hard Drives Set 2:

SATA-SAS RAID Controller:

SATA RAID Setup:

Storage Bay Configuration:

COMMUNICATIONS

NetWork:

USB Ports:

Wireless:

Mouse / Keyboard:

WARRANTY

Assembly:

TAA Compliance:

Warranty:

Extra Care:

Qty:

Technical Specs

Support

TITAN W69

TITAN W69 - Intel Xeon 6900 Series LGA 7529 High Performance for AI and Machine Learning Workstation Computer

Intel Xeon 6900-series processors are delivered in a new class of Intel server platform design, offering customers the high performance, high memory bandwidth, and high throughput ideal for cloud, HPC, and AI environments. These processors feature higher core counts, more memory channels, and I/O lanes with thermal design points that are higher than the other series.

The Intel Xeon 6900 series (Xeon 6 "Granite Rapids" processors) is designed for high-end servers, AI infrastructure, HPC clusters, large databases, and virtualization environments. Key benefits include:

Very High Core Counts

Up to 128 Performance (P) cores and 256 threads in a single socket.

Excellent for heavily threaded workloads such as virtualization, simulation, rendering, analytics, and cloud services.

Strong AI Performance

Includes Intel AMX (Advanced Matrix Extensions) with FP16 support for AI inference acceleration.

Can reduce the need for GPUs in some inference workloads and improve performance for AI-enabled enterprise applications.

High Memory Bandwidth

Supports 12 DDR5 memory channels per CPU.

Supports high-speed MRDIMM memory up to 8800 MT/s.

Particularly beneficial for in-memory databases, AI, scientific computing, and large-scale analytics.

Large Cache Capacity

Up to 504 MB of L3 cache.

Reduces memory latency and improves performance for data-intensive workloads.

Modern I/O and Expansion

Up to 96 PCIe 5.0 lanes and support for CXL 2.0.

Enables fast networking, NVMe storage, AI accelerators, and memory expansion technologies.

Better Virtualization Density

Higher core counts and memory capacity allow more VMs or containers per server.

Helps reduce rack space, power consumption, and software licensing costs in many enterprise environments.

HPC and Scientific Computing

Built specifically with strong per-core performance and advanced vector/matrix capabilities.

Well suited for engineering simulations, modeling, financial analytics, and technical computing.

Best Use Cases

- AI inference platforms

- VMware/Hyper-V virtualization hosts

- SAP HANA and large database servers

- Scientific/HPC clusters

- Cloud and hosting providers

- Large enterprise application servers

Rear Panel Ports:
2 x USB 3.0 Ports
2 x RJ45 by Ethernet Connection for 1GbE
1 x VGA Port ASPEED AST2500 w/ 256MB

Storage Related:
2 x M.2 slots (Key M)
4 x SATA 6Gb/s ports

Dimensions:
19.50" x 9.25" x 20.10"

Availability:
Usually Ships in 2 to 3 weeks

Product Code:
W69
